| Type designation |
![Shaft Ø [mm]](https://www.uhing.com/_assets/3cdf1a01bd93189764ad406844aec656/Icons/Variants/icon_shaft_diameter.svg){kind=icon} Shaft Ø [mm]
|
![Side thrust FRS [N]](https://www.uhing.com/_assets/3cdf1a01bd93189764ad406844aec656/Icons/Variants/icon_max_thrust_force_frs.svg){kind=icon} Side thrust FRS [N]
|
![max. speed v [m/s]](https://www.uhing.com/_assets/3cdf1a01bd93189764ad406844aec656/Icons/Variants/icon_max_speed_with_standard_momentum_switch.svg){kind=icon} max. speed v [m/s]
|
![Pitch/rev. [mm]](https://www.uhing.com/_assets/3cdf1a01bd93189764ad406844aec656/Icons/Variants/icon_max_pitch_per_revolution.svg){kind=icon} Pitch/rev. [mm]
|
|---|---|---|---|---|
|
KI3L-15-6MCR KI3R-15-6MCR |
15 | 30 | 0.3 | 6 |
|
RGK3-15-0MCRF |
15 | 90 | 0.3 | 8 |
|
RG3L-15-2MCRF RG3R-15-2MCRF |
15 | 110 | 0.3 | 11.1 |
|
RG4L-15-2MCRF RG4R-15-2MCRF |
15 | 220 | 0.3 | 11.1 |
|
RGK3-20-1MCRF |
20 | 130 | 0.3 | 12 |
|
RG3L-20-2MCRF RG3R-20-2MCRF |
20 | 160 | 0.3 | 15.5 |
|
RG4L-20-2MCRF RG4R-20-2MCRF |
20 | 320 | 0.3 | 15.5 |
|
RGK3-22-1MCRF |
22 | 130 | 0.3 | 13 |
|
RG3L-22-2MCRF RG3R-22-2MCRF |
22 | 160 | 0.3 | 16.5 |
|
RG4L-22-2MCRF RG4R-22-2MCRF |
22 | 320 | 0.3 | 16.5 |
|
RG3L-30-2MCRF RG3R-30-2MCRF |
30 | 260 | 0.4 | 24 |
|
RG4L-30-2MCRF RG4R-30-2MCRF |
30 | 520 | 0.4 | 24 |
|
RG3L-40-2MCRF RG3R-40-2MCRF |
40 | 420 | 0.4 | 32 |
|
RG4L-40-2MCRF RG4R-40-2MCRF |
40 | 840 | 0.4 | 32 |
|
RG3L-50-0MCR RG3R-50-0MCR |
50 | 700 | 0.25 | 40 |
|
RG4L-50-0MCR RG4R-50-0MCR |
50 | 1400 | 0.25 | 40 |
|
RG3L-60-0MCR RG3R-60-0MCR |
60 | 1000 | 0.25 | 48 |
|
RG4L-60-0MCR RG4R-60-0MCR |
60 | 2000 | 0.25 | 48 |
|
RG3L-80-0MCR RG3R-80-0MCR |
80 | 1800 | 0.25 | 70 |
|
RG4L-80-0MCR RG4R-80-0MCR |
80 | 3600 | 0.25 | 70 |
